礦山及工程用活塞式柴油系列空氣壓縮機 |
☆排氣壓力:0.5 – 0.7Mpa |
☆排氣量:1.35-13M3/Min |
☆電機功率范圍:11-75kW |
詳細資料下載 |
|
歷史悠久 譜系齊全 市場覆蓋率居空壓機行業首位 品種范圍:有固定式、移動式;風冷、水冷型;柴動型、電動型共100多個產品。
礦山及工程用活塞式空氣壓縮機參數 |
型號 |
配套動力(kW) |
排氣量(m3/min) |
排氣壓力(Mpa) |
外形尺寸(長×寬×高) |
W-1.35/5-D |
11 |
1.35 |
0.5 |
1390×640×980 |
W-1.35/5 |
S1100 |
1.35 |
0.5 |
1390×640×980 |
W-1.8/5-J-D |
11 |
1.8 |
0.5 |
1700×710×1000 |
W-1.8/5-J |
S1100 |
1.8 |
0.5 |
1700×710×1000 |
W-1.8/5-D |
11 |
1.8 |
0.5 |
1700×710×1000 |
W-1.8/5 |
S1100 |
1.8 |
0.5 |
1700×710×1000 |
W-2/5-D |
11 |
2 |
0.5 |
1700×810×1050 |
W-2/5 |
S1100 |
2 |
0.5 |
1700×810×1050 |
W-2.6/5-D |
15 |
2.6 |
0.5 |
1780×870×1235 |
W-2.6/5 |
S1110 |
2.6 |
0.5 |
1780×870×1235 |
W-2.8/5-D |
15 |
2.8 |
0.5 |
1780×870×1235 |
W-2.8/5 |
S1110 |
2.8 |
0.5 |
1780×870×1235 |
W-2.8/5-G-D |
15 |
2.8 |
0.5 |
1780×870×1235 |
W-2.8/5-G |
S1115 |
2.8 |
0.5 |
1780×870×1235 |
W-2.8/5-G-DZ |
15 |
2.8 |
0.5 |
1780×870×1235 |
W-3/5-D |
18.5 |
3 |
0.5 |
1800×900×1300 |
W-3/5 |
S1115 |
3 |
0.5 |
1800×900×1300 |
2V-3.5/5-D |
18.5 |
3.5 |
0.5 |
1800×950×1300 |
2V-3.5/5 |
S1125 |
3.5 |
0.5 |
1800×950×1300 |
2V-4/5-D |
18.5 |
4 |
0.5 |
1800×950×1300 |
2V-4/5 |
S1125 |
4 |
0.5 |
1800×950×1300 |
W-1.8/7-D |
11 |
1.8 |
0.7 |
1100×820×1100 |
W-1.8/7 |
S1100 |
1.8 |
0.7 |
1100×820×1100 |
W-2.6/7-D |
15 |
2.6 |
0.7 |
1800×870×1235 |
W-2.6/7 |
S1115 |
2.6 |
0.7 |
1800×870×1235 |
W-3.2/7-D |
18.5 |
3.2 |
0.7 |
1920×960×1350 |
W-3.2/7 |
S1125 |
0.7 |
0.7 |
1920×960×1350 |
W-2.5/3-D |
11 |
2.5 |
0.3 |
1780×870×1235 |
W-2.5/3 |
S1110 |
2.5 |
0.3 |
1780×870×1235 |
VF-3/7 |
18.5 |
3 |
0.7 |
1720×1100×1110 |
VF-6/7 |
37 |
6 |
0.7 |
2100×1100×1110 |
VFY-6/7 |
37 |
6 |
0.7 |
2830×1500×1890 |
VF-7/7 |
40 |
7 |
0.7 |
2100×1100×1110 |
CVF7/7 |
YC4108 |
7 |
0.7 |
2760×1200×1460 |
CVF7/7 |
QC4110 |
7 |
0.7 |
2760×1200×1460 |
VFY-7/7 |
40 |
7 |
0.7 |
2830×1500×1890 |
CVFY-7/7 |
YC4108 |
7 |
0.7 |
2830×1300×1890 |
CVFY-7/7 |
QC4110 |
7 |
0.7 |
2830×1300×1890 |
VF-9/7 |
55 |
9 |
0.7 |
2460×1200×1220 |
VFY-9/7 |
55 |
9 |
0.7 |
2830×1500×1900 |
VF-10/7 |
65 |
10 |
0.7 |
2460×1200×1220 |
VFY-10/7 |
65 |
10 |
0.7 |
2830×1500×1900 |
CVF-10/7 |
YC4108ZG |
10 |
0.7 |
3200×1350×1650 |
CVF-10/7 |
QC4112 |
10 |
0.7 |
3200×1350×1650 |
CVFY-10/7 |
YC4108ZG |
10 |
0.7 |
3200×1550×2230 |
CVFY-10/7 |
QC4112 |
10 |
0.7 |
3200×1550×2230 |
VF-13/7 |
75 |
13 |
0.7 |
2460×1200×1220 |
VFY-13/7 |
75 |
13 |
0.7 |
2830×1500×1900 |
CVF-13/7 |
YC6108ZG |
13 |
0.7 |
3300×1350×1470 |
CVF-13/7 |
CUMMINS 6BT5.9-C118 |
13 |
0.7 |
3300×1350×1470 |
CVF-13/7 |
QC6112 |
13 |
0.7 |
3350×1350×2100 |
CVFY-13/7 |
YC6108ZG |
13 |
0.7 |
3500×1600×2640 |
CVFY-13/7 |
CUMMINS 6BT5.9-C118 |
13 |
0.7 |
3500×1600×2340 |
CVFY-13/7 |
QC6112 |
13 |
0.7 |
3570×1600×2640 |
2V-6/7 |
37 |
6 |
0.7 |
1750×1100×1200 |
2V-7/7 |
40 |
7 |
0.7 |
1750×1100×1200 | |
|
|
|
|
